Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.
- Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
- Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
- Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
- Durable Finish - Baked-on enamel finish protects reel from corrosion
- Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications
| Application | Air, Water, Antifreeze, WWS |
|---|---|
| Color | Metallic Blue |
| Frame Type | Dual Pedestal |
| Hose Inside Diameter (in) | 1/2 |
| Hose Length (ft) | 35 |
| Hose Reel Type | Reel with Hose |
| Inlet Size (in) | 1/2 |
| Inlet Thread Gender | Male |
| Inlet Thread Type | NPSM |
| Maximum Temperature (°F) | 190 |
| Maximum Working Pressure (psi) | 300 |
| Minimum Temperature (°F) | -20 |
| Mount Location | Truck Mount, Bench Mount |
| Outlet Size (in) | 1/2 |
| Outlet Thread Gender | Male |
| Overall Height (in) | 22.5 |
| Overall Length (in) | 18.5 |
| Overall Width (in) | 7.5 |
| Recommended Environment | Indoor, Outdoor |
| Recommended Fluid Type | Air, Water, Antifreeze, WWS |
| Reel Thread Type | NPT |
| Series | 10 |
| Type | Spring-Rewind Reel |
| Wetted Parts | Stainless Steel, Anodized Aluminum, Nitrile Rubber |
